WITH CE, SGS, TUV, BV Certificate
| Model | HL-150(A~F) | HL -225(A~F) | HL -408(A~F) | HL -800(A~F) | HL -1000(A~F) | ||||
| Internal Dimensions WxHxD (mm) |
500x600x500 | 600x750x500 | 600x850x800 | 1000x1000x800 | 1000x1000x1000 | ||||
| External Dimensions WxHxD (mm) |
1050x1750 x1050 | 1200x1900 x1150 | 1200x1950 x1350 | 1600x2000 x1450 | 1600x2100 x1450 | ||||
| Temperature Range | Low Temperature(A:25ºC B:0ºC C:-20ºC D:-40ºC E:-60ºC F:-70ºC) High Temperature 150ºC |
||||||||
| Humidity Range | 20%R.H.~98%R.H. (5%R.H. is optional) | ||||||||
| Analytic Accuracy/ Distribution Uniformity of Temperature | 0.1ºC /±2.0ºC | ||||||||
| Control Accuracy of Temperature | ±0.5ºC | ||||||||
| Temperature Rising/ Falling Velocity |
Temperature rising approx. 0.1~3.0ºC/min ; temperature falling approx. 0.3~1.0ºC/min; ( faster change rate is optional) |
||||||||
| Internal and External Material |
Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or SEE cold-rolled steel with paint coated. | ||||||||
| Insulation Material |
Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
||||||||
| Cooling System | Wind cooled or water cooled,single segment compressor for -40ºC, double segment compressor for -70ºC | ||||||||
| Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, Over-humidity and over-temperature protection switch, fuses, fault warning system | ||||||||
| Optional Accessories | Inner door with operation hole(Optional), Recorder(optional),Dehumidifier | ||||||||
| Compressor | French Tecumseh Brand,Germany Bizer Brand | ||||||||
| Power | AC 220V, 1 phase 3 Lines,50/60HZ ; AC 380V ,3 phase 5 Lines,50/60HZ | ||||||||
| Approx. Weight (Kg) | 180 | 250 | 320 | 400 | 450 | ||||
