Vibration Shaker Table is a new type of electrodynamic shaker systems with a Max Displacement of 51mm, 2 Pcs acceleration sensor and a Max Load of 100kg. It is designed to meet test standard including Mil-std-810, IEC60068-2-64,RTCA DO-160 and IEC 61373. The electrodynamic vibration shaker system is made of high quality materials and designed to provide reliable and efficient performance for a wide range of vibration testing applications.
The vibration shaker table is equipped with a low-noise, high-power electrodynamic shaker system, allowing it to generate highly precise and repeatable vibration testing with a wide range of frequency and amplitude. The shaker system can also be easily adjusted to meet different test requirements.
The vibration shaker table is a reliable and efficient system for a variety of vibration testing applications. It is designed to provide accurate, repeatable results with minimal noise and vibration levels. The vibration shaker table is an ideal choice for vibration testing in a variety of industries.
ASLI ES Series Vibration Shaker Table is a superior electrodynamic shaker system that provides precise and repeatable vibration testing. It is mainly used for vibration testing products, components, materials, and structures. This vibration shaker table is designed to simulate various environmental conditions and accurately test the performance of components and products. It is widely used in various research and development, quality control, and production fields.
This vibration shaker table is equipped with advanced electrodynamic technology and can provide up to 20g acceleration sensor with high-precision response. The computer-controlled system ensures accurate vibration testing and can measure displacement, acceleration, velocity, and force. The durable design ensures long-term stability and reliability. The voltage is 380V/50Hz, and the minimum order quantity is 1 set.
ASLI offers CE and ISO9001 certifications for its vibration shaker tables and provides one-year warranty. Its competitive price and superior quality make it the best choice for customers. The company can supply 300 sets per year and provide strong export plywood case packaging. The delivery time is 35~40workdays, and customers can pay via T/T or L/C.
| Name | Parameter |
|---|---|
| Max Displacement | 51mm |
| Test Standard | Mil-std-810, IEC60068-2-64,RTCA DO-160,IEC 61373 |
| Max Load | 100kg |
| Control System | Computer |
| Name | Vibration Shaker Table |
| Surface Treatment | Paint |
| Max Velocity | 2m/s |
| Application | Auto Part, Battery, LED |
| Certification | CE, ISO9001 |
| Size | Customized |
| Electrodynamic Vibration Shaker System | Electrodynamic Vibration Shaker System |
ASLI's ES Series Vibration Shaker Table provides a cost-effective solution for vibration testing of components, sub-assemblies and finished products. Featuring reliable and robust performance, the Vibration Shaker Table is perfect for a wide range of applications such as auto part, battery, LED testing. It features a frequency range from 3-3500 Hz, and can perform sine, random, shock, ROR, SOR, and other vibration tests. The Vibration Shaker Table come with two acceleration sensors, and is made of steel material.
Brand Name: ASLI
Model Number: ES Series
Place of Origin: CHINA
Certification: CE
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Strongly Export Plywood Case
Delivery Time: 35~40 Workdays
Payment Terms: T/T, L/C
Supply Ability: 300 Sets Per Year
We provide technical support and service for our customers to ensure their satisfaction with our Vibration Shaker Table products.
Our technical support team is available to assist with troubleshooting and answer any questions you may have. We also provide regular maintenance and repair services to ensure optimal performance of the product.
Our customer service team is available to help with any issues or questions you may have. We are committed to providing the highest level of customer service and satisfaction.
If you have any questions or need assistance with your Vibration Shaker Table product, please contact us and we will be happy to help.
Packaging and Shipping for Vibration Shaker Table:
